Yamaha Outboard Parts - Electric Parts 2 - 50DEMTO (1987) | Flood Marine

Diagram: Electric Parts 2

Diagram

Parts List

Reference
Description
Price


1
6H4821050000
Battery cable
Loading…

↗
2
688819501000
Relay assembly
Loading…

↗
5
6G1819706200
Rectifier assembly
Loading…

↗
9
6H4861120000
Stay, Solenoid
Loading…

↗
12
6H4427242000
Grommet
Loading…

↗
13
6H4427250000
Grommet 2
Loading…

↗
14
676427260000
Grommet 3
Loading…

↗
15
6H4825902100
Wire Harness Assembly
Loading…

↗
16
6H4825880000
Plate
Loading…

↗
23
6H4825540000
Stay, Neutral Switch
Loading…

↗
24
6H4441730100
Lever Shift Control
Loading…

↗
29
688819490000
Wire, Lead
Loading…

↗
30
6H1825630100
Trim & tilt switch assembly
Loading…

↗
31
6E5825870000
Gasket
Loading…

↗
32
6E5836140000
Bracket
Loading…

↗
33
6H3825530000
Extension, Wire
Loading…

↗
36
6H3821640000
Case 2
Loading…

↗
