FT9.9AMH (1986)
Repair Kit
Diagram: Repair Kit
Parts List
Reference
Description
Price
1
6G8W00010000
Power Head Gasket Kit
Loading…
↗
2
6G8411120000
Gasket, exhaust inner cover
Loading…
↗
3
6G8124140000
Gasket, cover
Loading…
↗
4
6G8111810000
Gasket, cylinder head 1
Loading…
↗
5
9321011M5900
O-ring (6g8)
Loading…
↗
6
9321013M6300
O-ring (6g8)
Loading…
↗
7
9321024M6600
O-ring
Loading…
↗
8
6G8113510000
Gasket, cylinder
Loading…
↗
11
9310218M2100
Oil seal (6g8)
Loading…
↗
12
6G8133290000
Gasket, Pump Cover
Loading…
↗
13
6G813646A000
Gasket,intake manifold 2
Loading…
↗
14
6G8136450000
Gasket, intake manifold
Loading…
↗
15
6G8141980000
Gasket
Loading…
↗
16
6G8153740000
Gasket, breather
Loading…
↗
17
6G8W00930000
Carburetor repair set
Loading…
↗
19
6G8143840000
Gasket, float chamber
Loading…
↗
20
647143860000
Pin, float
Loading…
↗
21
654141980000
Gasket
Loading…
↗
22
6G8143230000
Screw, air adjusting
Loading…
↗
23
6G8143920000
Valve, needle
Loading…
↗
24
6G8143850000
Float assembly
Loading…
↗
26
929030410000
Ybs67-4 washer, spring
Loading…
↗
27
33A143690000
Diaphragm Assembly
Loading…
↗
28
1J2143970000
O-Ring
Loading…
↗
29
5H0143970000
O-ring
Loading…
↗
30
5Y1143970000
O-ring
Loading…
↗
32
6G8153120000
Gasket, Oil Pan
Loading…
↗
33
932101677200
O-ring (m124)
Loading…
↗
35
9321008M6000
O-ring (6g8)
Loading…
↗
36
9310113M2700
Oil seal (6g8)
Loading…
↗
37
6G841133A000
Gasket,exhaust manifold 1
Loading…
↗
38
6G8451130000
Gasket,upper casing
Loading…
↗
39
904300802000
Gasket
Loading…
↗
40
682443150000
Gasket,water pump 1
Loading…
↗
41
931022048400
Oil seal
Loading…
↗
42
6G8453150000
Packing, lower casing
Loading…
↗
43
931011705400
Oil seal (17x30x6-650)
Loading…
↗
44
9321074M6800
O-ring (6g8)
Loading…
↗
45
682453750100
Damper, seal
Loading…
↗
46
626443650100
Damper, water seal 1
Loading…
↗
47
682W00780000
Water pump repair kit
Loading…
↗
48
682443650000
Damper, water seal 1
Loading…
↗
49
682443220000
Insert, cartridge
Loading…
↗
50
682443520100
Impeller
Loading…
↗
51
902800302400
Key, woodruff(662)
Loading…
↗
53
682443230000
Outer plate, cartridge
Loading…
↗
54
973950604500
Bolt, hexagon
Loading…
↗
